High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room

All Products
All in One Integrated Led Screen (0)
COB Integrated LED display (1)
Hot Sell (10)
In Stock (10)
Curved LED Rental Screen (5)
COB LED Screen (10)
HD Indoor LED Screen (10)
Outdoor LED Screen (10)
Rental LED Display (10)
Transparent LED Screen (10)
I'm Online Chat Now

High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room

High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room
High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room

Large Image :  High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room

Product Details:
Place of Origin: Guangdong, China
Brand Name: DDW or Customized
Model Number: DCOB series
Contact Now
Detailed Product Description
Warranty: 5 Years Type: LED
Application: Indoor Use: Advertising Publish, Retail Store, Shopping Mall, Welcome Display, Exhibition Hall, Airport, Subway, Restaurant & Hotel Supplies, Education
Media Available: Photo, EDA/CAD Models, Datasheet Pixel Density: 409,600dots/m2
Pixels: P1.56 Pixel Pitch: 1.56mm
Module Size: 150*168.75mm Pixel Configuration: COB
Maintenance Method: Front Maintenance Cabinet Size: 600*337.5*29mm
Cabinet Weight: 3.8KG Cabinet Material: Die Cast Aluminum
Refresh Frequency: 3840~7680 Grayscale: 16bit
Brightness (nits)(Colour Temp 6500K): Factory Delivery Standard: 1000 After Calibration Panel Size: 600x337.5x29mm

High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room 0
High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room 2
High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room 4
High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room 6
High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room 8
Products Description
High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room 10
High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room 12
High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room 14
High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room 16
High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room 18
High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room 20
Specifications
Item
High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room
Pixel Pitch (mm)
P0.78
P0.9375
P1.25
P1.5625
Module resolution
205x230
160x180
120x135
96x108
Module size (mm)
150x168.75
Cabinet resolution
820x460
640x360
480x270
384x216
Cabinet size (mm)
600x337.5x29
Normal weight (kg/m²)
23
Pixel density (dots/m²)
1508800
1137777
640000
409600
Cabinet flatness (mm)
≤0.15
Single-point brightness correction
yes
Single-point color correction
yes
Brightness (nits)
600-1200
Color temperature (K)
3000-10000 adjustable
Viewing angle
170°/170°
Chroma uniformity
±0.003
Frame rate (Hz)
50&60
Refresh rate (Hz)
3840/7680
Center distance deviation
＜3%
Brightness uniformity
≥97%
40 ° C/RH90% test
Through testing
Company Profile
High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room 22
High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room 24
High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room 26
High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room 28
High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room 30
High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room 32
High End COB GOB Fine Pitch P0.7 P0.9 P1.2 P1.5 LED Video Wall Panel 2K 4K 8K Resolution COB LED Display for Monitor Room 34
Q:Who Are We? A: DDW DISPLAY has 12,000sqm high-tech automated workshop, 100 employees,25 research engineers,20 after-sale technicians,4000sqm productivity each month. Q: How Can We Guarantee Quality? A: Seven quality control steps ensure your ordered screens good: 1. Suppliers are long-term cooperated large famous company. 2. Material check by professional workers and machines. 3. Debug every modules. 4. 48-hour aging test for all modules before assembling. 5. Test every cabinet's function after assembling by engineers and machines. 6. 72-hour aging test for whole screen before shipment. 7. All details final inspection again before package.
Q: What Can You Buy From Us? A: indoor outdoor rental LED screen, fixed LED screen, HD LED screen, flexible LED screen, transparency LED display, creative led screens and customization services.

Q: Why Should You Buy From US Not From Other Suppliers? A: After the 12 years development, Shenzhen DDW Technology Co.,Ltd has accumulated rich experience of R&D and has the first-class automated production equipment, standard clean automation production plant and anti-static system devices. Q: What Services Can We Provide? A: 5-years quality warranty and life-long repairing service. If any components need to repair or replace, you can send it back to Shenzhen.
