Outdoor Fixed Giant 3D Led Video Wall Billboard Advertising Panel P5 P6 P8 P10 HD Naked-Eye LED Display Screen With Corner

Name: Outdoor Fixed Giant 3D Led Video Wall Billboard Advertising Panel P5 P6 P8 P10 HD Naked-Eye LED Display Screen With Corner
Brand: Shenzhen DDW Technology Co., Ltd.
SKU: FA Series
Availability: InStock

Large Image : Outdoor Fixed Giant 3D Led Video Wall Billboard Advertising Panel P5 P6 P8 P10 HD Naked-Eye LED Display Screen With Corner

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	DDW
Model Number:	FA Series

Contact Now

Detailed Product Description

Warranty:	5 Years	Type:	LED
Application:	Outdoor	Use:	Advertising Publish, Retail Store, Shopping Mall, Welcome Display, Exhibition Hall, Airport, Subway, Restaurant & Hotel Supplies
Media Available:	Datasheet, Photo, EDA/CAD Models	Color:	16bit
Pixel Density:	10000dots/m2	Pixels:	10mm, 6, 8, 5
Pixel Pitch:	10 Mm	Module Size:	480*320mm
Lamp Type:	SMD1921	Gray Scale:	16bit
Brightness Level:	8000-10000nits	Cabinet Material:	Alumimum
Cabinet Weight:	28kg	Protecting Rating:	IP68
Refresh Rate:	3840Hz-7680Hz	Maintenance Mode:	Front Or Rear Maintenance

Products Description

Specifications

Item	High Quality Outdoor Fixed Giant 3D Led Video Wall Advertising Panel P5 P6 P8 P10 HD Naked-Eye LED Display Screen With Corner
Pixel Pitch (mm)	5mm	6.667mm	8mm	10mm
Packaging method	SMD 1921 Triple In - (Six Leg Lamp)
Brightness	8000-10000cd/m²
Module resolution	96x64 Dots	72x48 Dots	60*40Dots	48x32 Dots
Module size (WxH)	480mmx320mm
Pixel density	40000 pixels/m²	22500 pixels/m²	15625pixels/m²	10000pixels/m²
Cabinet resolution	192x192Dots	144x144 Dots	120*120Dots	96x96 Dots
Cabinet size (WxHxD)	W960mmxH960mmxD100mm
Cabinet weight	27kg/m²
Maintenance method	Front and rear maintenance
Protection level	Front IP68 and rear IP66
Cabinet flatness	≤0.4mm
Module/box material	Aluminum/Die cast Aluminum
Module connection method	Hard connection design
Module signal connection point	Dual backup redundancy
Color temperature	Adjustable from 2000K to 15000K
Viewing angle	Horizontal>160 °, vertical>110 °
Physical contrast (black/white)	8:1	10:1	15:1	24：1
Reflective coefficient (white ratio)	12%	9%	6.30%	4%
Maximum power	700W/m²	650W/m²	660W/m²	650W/m²
Average power	70-180W/m²
Power parameters	AC 100~240V/low voltage power supply
Grayscale	16bit
Refresh rate	7680Hz
Frame frequency	50/60 Hz
LED lamp life	100.000 Hours
Operating temperature/humidity range	-20℃~+60℃C/10~90%RH

Company Profile

Q:Who Are We? A: DDW DISPLAY has 12,000sqm high-tech automated workshop, 100 employees,25 research engineers,20 after-sale technicians,4000sqm productivity each month. Q: How Can We Guarantee Quality? A: Seven quality control steps ensure your ordered screens good: 1. Suppliers are long-term cooperated large famous company. 2. Material check by professional workers and machines. 3. Debug every modules. 4. 48-hour aging test for all modules before assembling. 5. Test every cabinet's function after assembling by engineers and machines. 6. 72-hour aging test for whole screen before shipment. 7. All details final inspection again before package.

Q: What Can You Buy From Us? A: indoor outdoor rental LED screen, fixed LED screen, HD LED screen, flexible LED screen, transparency LED display, creative led screens and customization services.

Q: Why Should You Buy From US Not From Other Suppliers? A: After the 12 years development, Shenzhen DDW Technology Co.,Ltd has accumulated rich experience of R&D and has the first-class automated production equipment, standard clean automation production plant and anti-static system devices. Q: What Services Can We Provide? A: 5-years quality warranty and life-long repairing service. If any components need to repair or replace, you can send it back to Shenzhen.
