Factory Direct Full Color Custom Fixed TV Display Panel Huge Digital Billboard Advertising P6.67 P8 P10 Outdoor Led Screen

Large Image : Factory Direct Full Color Custom Fixed TV Display Panel Huge Digital Billboard Advertising P6.67 P8 P10 Outdoor Led Screen

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	OEM/ODM
Model Number:	FO series

Contact Now

Detailed Product Description

Warranty:	5 Years	Type:	LED
Application:	Outdoor	Use:	Advertising Publish, Retail Store, Shopping Mall, Welcome Display, Self-service Business, Exhibition Hall, Wayfinding, Airport, Subway, Elevator, Education, Medical Treatment
Media Available:	Photo, EDA/CAD Models, Datasheet	Pixels:	Other
Pixel Pitch:	10 Mm	Module Size:	320*160mm
Usage:	Outdoor HD	Cabinet Material:	Aluminum Module
Cabinet Weight:	40KG/m²	Refresh Rate:	3840Hz
Control System:	Novastar System	Maintenance Mode:	Front Or Rear Maintenance
Product Name:	Outdoor Led Screen	Certificate:	CE ROHS FCC CCC ISO9001

Discover Your Right Application , Make Your Business Possible !

Common warranty in LED field is 2 years, ours is 3 years Longer warranty periods, better after-sale services, worry-free user experience

Products Description

Specifications

Model	P3	P3.91	P4	P5	P6	P8	P10
Module size(mm)	320×160	250x250	320×160	320×160	192×192	320×160	320×160
Module resolution (dot)	64×64	64×65	80×40	64×32	32×32	40×20	32×16
Scanning	1/16S	1/17S	1/20S	1/8S	1/8S	1/5S	1/2S
SMD	1G1R1B	1G1R2B	1G1R1B	1G1R1B	1G1R1B	1G1R1B	1G1R1B
Maintenance	Back	Back	Back	Back	Back	Back	Back
Installation	Back	Back	Back	Back	Back	Back	Back
Cabinet size(mm)	960×960	1000×1000	960×960	960×960	960×960	960×960	960×960
Density(dot/㎡)	111111	65410	62500	40000	27777	15625	10000
Brightness(cd/㎡)	4200-4500	4200-4501	5000-6500	5000-6000	5000-6000	4000-5000	6000-7500
Max. Power Consumption	1000	1001	900	800	800	800	1000
Average Power Consumption	350	351	300	400	300	300	500
Cabinet weight (kg/m²)	40kg	41kg	40kg	40kg	40kg	40kg	40kg
Cabinet material	Iron	Iron	Iron	Iron	Iron	Iron	Iron
IP rate	IP 65	IP 66	IP 65	IP 65	IP 65	IP 65	IP 65
Grayscale	10000:1	10000:2	10000:1	10000:1	10000:1	10000:1	10000:1
Refresh rate(hz)	1920-3840	1920-3841	1920-3840	1920-3840	1920-3840	1920-3840	1920-3840
Frame change frequency	50/60hz	50/61hz	50/60hz	50/60hz	50/60hz	50/60hz	50/60hz
Horizontal viewing angle	>140°	>141°	>140°	>140°	>140°	>140°	>140°
Vertical viewing angle	>140°	>141°	>140°	>140°	>140°	>140°	>140°
Best viewing distance	>3m	>4m	>4m	>5m	>6m	>8m	>10m
Input Voltage	AC110V – AC220V	AC110V – AC221V	AC110V – AC220V	AC110V – AC220V	AC110V – AC220V	AC110V – AC220V	AC110V – AC220V
Module Max. current	4.5-5.5	4.5-5.6	5.5-7.5	5.5-7.5	3.5-5.5	5.5-7.0	8.0-10
Temperature-operating	﹣10℃～60℃	﹣10℃～61℃	﹣10℃～60℃	﹣10℃～60℃	﹣10℃～60℃	﹣10℃～60℃	﹣10℃～60℃
Humidity-operating	10%～90%	10%～91%	10%～90%	10%～90%	10%～90%	10%～90%	10%～90%
Life span (H)	≥100,000	≥100,001	≥100,000	≥100,000	≥100,000	≥100,000	≥100,000
MTBF (H)	>10,000	>10,001	>10,000	>10,000	>10,000	>10,000	>10,000
