High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen

All Products
All in One Integrated Led Screen (0)
COB Integrated LED display (1)
Hot Sell (10)
In Stock (10)
Curved LED Rental Screen (5)
COB LED Screen (10)
HD Indoor LED Screen (10)
Outdoor LED Screen (10)
Rental LED Display (10)
Transparent LED Screen (10)
I'm Online Chat Now

High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen

High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen
High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen

Large Image :  High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen

Product Details:
Place of Origin: Guangdong, China
Brand Name: DDW or OEM
Model Number: FU Series
Contact Now
Detailed Product Description
Warranty: 5 Years Type: LED
Application: Indoor Use: Advertising Publish, Retail Store, Shopping Mall, Display Of Dishes, Welcome Display, Self-service Business, Exhibition Hall, Wayfinding, Airport, Subway, Elevator, Restaurant & Hotel Supplies, Education, Medical Treatment
Media Available: Photo, EDA/CAD Models, Datasheet Pixel Density: 160000Pixels/m²
Pixels: 2.5mm Pixel Pitch: 2.5mm
Module Size: 250mmx250mm Lamp Type: SMD1515
Usage: Indoor HD Cabinet Material: Alumimum
Cabinet Weight: 6.4kg Refresh Rate: 3840Hz-7680Hz
Gray Scale(bit): 14bit-16bit Control System: Novastar System
Maintenance Mode: Front Maintenance Panel Size: 1000*250mm

High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen 0
High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen 2
High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen 4
High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen 6
Products Description
High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen 8
High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen 10
High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen 12
High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen 14
High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen 16
High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen 18
Specifications
Item
High Quality Small Pitch 640x480 Aluminum HD Led Panel P1.25 P1.56 P1.86 P2.5 3840Hz Seamless Splicing 4k Indoor Led Screen
Specs\Applications
Indoor 1000*250/750*250/500*250
Model
FU-1.5
FU-1.9
FU-2.5
FU-2.6
FU-2.9
FU-3.9
Pixel Pitch
1.56mm
1.95mm
2.5mm
2.6mm
2.9mm
3.91mm
Optional processes
SMD,GOB
SMD,GOB
SMD+Mask
SMD+Mask
SMD+Mask
SMD+Mask
Lamp Types
SMD1212
SMD1515
SMD1515
SMD1515
SMD1515
SMD2121
Lamp brand
Standard version SINYOPTO, High end version National Star
IC DRIVE
CFD455
Scan
1/40S
1/32S
1/25S
1/32S
1/28S
1/16S
Module size(mm)
250mmx250mm
Module Resolution(Pixels/pcs)
160*160
128*128
100*100
96*96
84*84
64*64
Module weight(kg)
0.35kg
0.35kg
0.35kg
0.35kg
0.35kg
0.35kg
Cabinet size(mm)
1000*250/750*250/500*250
Cabinet resolution(Pixels/pcs)
640*320/480*320/320*320
512*256/384*256/256*256
400*100/300*100/200*100
384*96/288*96/192*96
336*84/*252*84/168*84
256*64/192*64/128*64
Cabinet Weight(kg)
6.4kg/5kg/3.5kg
5.8kg/4.4kg/2.9kg
5.8kg/4.4kg/2.9kg
5.8kg/4.4kg/2.9kg
5.8kg/4.4kg/2.9kg
5.8kg/4.4kg/2.9kg
Pixel density(Pixels/m²)
409600
262144
160000
147456
112896
65536
Material
Aluminum Profile
Real Brightness(cd/m²)亮度
800-1000
800-1000
800-1000
800-1000
800-1000
1000-1200
Grey grade
14bit
14bit
14bit
14bit
14bit
14bit
Refresh rate
7680Hz
Input Voltage
110-220V
Power Consumption(Max.W/m²)
560W
Power Consumption(Ave.W/m²)
280W
IP rating(Front/Rear)
IP31
Operating temperature
-20℃ ~ +45℃
Operating humidity
10% ~90%RH
Storage temperature
-10℃ ~ +40℃
Storage humidity
10% ~60%RH
Lifespan (Hrs)
≥50,000
